VAULT®
The VAULT dual plug system enables two Archer barrier plugs to be installed in one run. VAULT streamlines plug operations with the ultimate goal of reducing operational (rig) time.
Application
• Plug and Abandonment (P&A)
• Barrier
Features
• Dual plug system
• ISO 14310 certified, available as a V0 rating
• No set weight needed below
• High differential pressure elements
Benefits
• Saves operational time
• Saves operational costs
• Reduced rigsite handling
• Improving safety standards
| Size, inches | 9 5/8 - 14 |
| Pressure rating, psi [bar] | 6,090 - 7,500 [420 - 517] |
| Temperature rating, ºF [ºC] | 39 - 311 [4 - 155] |
| ISO 14310 qualification | V0 - V6 |
| Max hang-off weight, k lbs [tons] |
300 [154]
|
