Tornar® BOP Cleaner

The Tornar® Sub Sea BOP Cleaner removes wellbore debris from blow out preventer and marine riser cavities safely, rapidly and reliably. Tornar® flow ports create a high-velocity fluid vortex, which combines with powerful proprietary magnets to extract debris — while maintaining full well control.

The Tornar® Sub Sea BOP Cleaner ensures the maximum extraction of harmful debris from BOP cavities and marine risers—without harming the BOP.

The Tornar® Sub Sea BOP Cleaner can be configured to suit operational requirements, for example by adjusting the ratio of flow ports to magnets, in order to maximize debris retrieval.

Application
• Removes wellbore debris from blow out preventer and marine riser

Features
• Tornar technology creates powerful vortex suction effect
• 3-stage circulation ports enable full well control
• Tornar Extreme magnets ensure maximum metallic debris extraction
• Easily configured to suit BOP and riser requirements
• One piece mandrels
• Non-rotating stabilizer and magnet.
• Built-in junk basket; spring-loaded self-adjusting dual brush
• Optional fishing magnet can be fitted to bottom of string

Benefits
• Rapid and effective single-trip BOP and riser cleaning
• Reduced BOP maintenance and nonproductive time
• Higher success rate and efficiency of BOP
• Allows short tripping with wellbore clean-up string
• Cleans even deep cavities

Download PDF Data Sheet

Cleaner string, inch [mm]	17.45 [443.2]
BOP size, inch [mm]	18.75 [476.3]
Recommended pump rate 6,500	6,500
Min. recommended pump rate, ipm	3,500
Material (main body)	AISI 4145M
Max working temp, deC [degF]	150 [302]
Max. OD, inch [mm]	17.45 [443.2]
Drift ID, inch [mm]	2.637 [67]
Tool joint OD, inch [mm]	7.252 [184.2]
Connections	5 1/2" FH b/p or VX 57 b/p
